HIRSCHMANN MCS
5.6 Screen Capture
The system has the capability of taking screenshots and saved to either:
1. USB Drive
2. Internal Memory
5.6.1 Taking Screen Captures
On any screen:
o Press and hold the “HOME” function button
o Press the “SET” function button
o Release both the “HOME” and “SET” function buttons simultaneously
o A screen shot of the current screen will be saved.
5.6.2 Saving Screen Captures
If a USB drive is installed in the console, the screen capture will be saved to the USB drive.
If a USB drive is not installed in the console, the image will be saved to the internal memory of the
console.
If using internal memory, only 20 images may be saved. After 20 images are saved, additional screen
captures will not be saved. The saved images can be transferred to a USB drive. This is done by:
1. Installing a USB drive
2. Take a new screenshot.
Once a screenshot is taken the images in internal memory are copied to the USB drive and
removed from internal memory.
