WIKA Mobile Control LP
1540 Orchard Drive
Chambersburg, PA 17201
qSCALE maestro (PLC v01.00.00) Service Manual / Issue E (HMI v1.0.0) 04/2018 / rbm.
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.wika-mc.com
61
/76
HIRSCHMANN MCS
7 Appendix
This appendix contains additional technical information and the full table of error codes.
7.1 Technical Data
Operating voltage 9…36 V DC,
suitable for 12 and/or 24 V on-board power supply
Overvoltage protection overvoltage up to max. 48V DC / 2 minutes
Reverse polarity protection up to -48V DC
Display 4.3“ TFT Color Graphic LCD, 480 x 272 Pixel (WVGA)
Or 7“ TFT Color Graphic LCD, 800 x 480 Pixel (WVGA)
Brightness 400 cd/m²
Contrast 400:1 or 500:1
Illumination LED, adjustable brightness
Audible alarm built-in, output for external horn
Dimensions See drawings below.
Operating temperature range -40ºC to +75ºC
Protection class IP66 and IP67 according to ISO 20653: Road Vehicles – Degrees of
protection (IP-Code) – Protection of electrical equipment against for-
eign
objects, water and access
Scope of supply - vSCALE D2 / D3 maestro console (depending on scope
of delivery with pre-fitted bracket for RAM Mount)
- Mount articulated mounting
- User manual (PDF file or on data storage device)
