HIRSCHMANN MCS
4.3 Sensor Calibration
Summary
To calibrate the sensors you must position the machine as directed to set minimum
and maximum values. Calibrating the sensors can be accessed through the System Menu. To
calibrate sensors an LMI or System Password is required.
 
HOME SETTINGS SENSOR
CALIBRATION
Function Keys
Calibrate Angle Sensor Calibrate Length Sensor
Luffing Cylinder Tuning
