7.6 Error Codes Table
The first one or two digits of an error code can determine what type of error is occurring
00xx
General Error
Other
2xxx Module Error
3xxx Module Error
1Fxx System
01xx
Limiter Error
Global Cut
02xx Single Cut
03xx Error
04xx Warning
05xx Pre-Warning
0Axx
Kinematic Error
Kinematic
0Bxx Kinematic
11xx
Parameter Errors
Cable Break / Lower Limit
12xx Short-Circuit to Ground
13xx Short-Circuit / Upper Limit
14xx Module Error
15xx Output Deactivated
16xx Sensor Supply Voltage Error
17xx Data Error / CAN Error
18xx Timeout / CAN Timeout
19xx Safety Error
1Axx Parameter Error
1Bxx Unspecified Error
