3.5 Overview Feedback Elements
Light Sensor: Not Used
Operating Display: Green While Supply Voltage is Connected
USB Data Display: Yellow During Data Exchange via Front USB Port
Wireless Indicator: Not Used
Multi-Function Light:
/ Flashes Red/White while in error state
Blue while setting the operating mode
Green while in operation
Yellow Machine nearing operational limit
