3.1 Product Identification
The type plate carries the unique identification of the operating console. It is located on the back of the
device.
Please ensure you make a note of all the information on your type plate for queries about this product.
3.2 General Information
NOTE
Knowledge of how to use a voltmeter to measure both voltage and current is as-
sumed.
HINT
For general system operation, refer to the console Operator’s Manual.
3.3 EC Conformity Declaration
The technical design and construction of the qSCALE maestro system corresponds to requirements of
the EMC directive 2004/108/EC and therefore carries the CE symbol.
The device complies with the following standards:
EN 12895:200, EN 13309:2010, EN ISO 14982: 2009
The full conformity declaration is available from the manufacturer on request.
Type plate
(Example for D3)
