WIKA Mobile Control LP
1540 Orchard Drive
Chambersburg, PA 17201
qSCALE maestro (PLC v01.00.00) Service Manual / Issue E (HMI v1.0.0) 04/2018 / rbm.
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.wika-mc.com
41
/76
HIRSCHMANN MCS
5.8 Maintenance and Repair
The qSCALE S6 maestro central control unit and vSCALE D2 / D3 maestro console contain no
wearing parts and therefore cannot be opened. If you notice malfunctions or differences between
measured and displayed values, you should switch the device off and have it checked and, if neces-
sary, repaired immediately by an authorized WIKA service partner.
Clean the surface and the front screen of the device occasionally with a damp cloth and a mild deter-
gent. Never use abrasive or aggressive detergents as these may damage the device.
IMPORTANT
Device may be damaged by the use of high-pressure cleaners.
The device must not be treated with a high-pressure cleaner or similarly aggressive method
under any circumstances!
Condensation inside the vSCALE D2 / D3 maestro console can damage electronic components or the
LCD and can condense at the inner side of the front glass/touch. Although the vSCALE D2 / D3 maes-
tro console is designed as a closed housing with a Gore-Tex-Membrane for breathing, condensation
may occur as a physical effect, if the console is exposed to unfavorable temperature/humidity cycles,
which pumps humidity inside the housing.
Damage to the front foil can lead to the penetration of moisture and dirt into the interior of the device,
which must then be properly repaired without delay.
Keep the contacts and the area around the device connectors clean and check occasionally that all
connections are secure.
If parts are damaged, they must be properly repaired or replaced immediately.
