Hirschmann qSCALE maestro User Manual

WIKA Mobile Control LP
1540 Orchard Drive
Chambersburg, PA 17201
qSCALE maestro (PLC v01.00.00) Service Manual / Issue E (HMI v1.0.0) 04/2018 / rbm.
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.wika-mc.com
69 /76
HIRSCHMANN MCS
Error Code Description Solution
Limiter Errors
0100 – 05FF
E0100 Min radius limit underrun (global cut) Boom down to a valid load-chart radius and angle
E0101 Max radius limit exceeded (global cut) Boom up to a valid load-chart radius and angle
E0102 Main boom angle too low (global cut) Boom up to a valid load-chart radius and angle
E0103 Main boom angle too high (global cut) Boom down to a valid load-chart radius and angle
E0104 Jib angle limit underrun (global cut) Move the jib up to a load chart permissible radius or angle
E0105 Jib angle limit exceeded (global cut)
Move the jib down to a load chart permissible radius or
angle
E010A Slew angle left to large (global cut) Return to the permitted Working Range (load chart)
E010B Slew angle right to large (global cut) Return to the permitted Working Range (load chart)
E010C Min length limit underrun (global cut) Telescope into the permitted Working Range (load chart)
E010D Max length limit exceeded (global cut) Telescope into the permitted Working Range (load chart)
E010E Min height limit underrun (global cut)
Move the boom into the permitted Working Range (load
chart)
E010F Max height limit exceeded (global cut)
Move the boom into the permitted Working Range (load
chart)
E012D Max length limit exceeded (global cut) Telescope into the permitted Working Range (load chart)
E0140 Min radius limit underrun (global cut) Move the Jib down to a valid radius and angle
E0141 Max radius limit exceeded (global cut) Boom up to a valid radius and angle
E0142 Main boom angle too low (global cut) Boom up to a valid radius and angle
E0143 Main boom angle too high (global cut) Move the Jib down to a valid radius and angle
E0144 Jib angle limit underrun (global cut) Move the jib up to a valid radius or angle
E0145 Jib angle limit exceeded (global cut) Move the jib down to a valid radius or angle
E0146 Jib angle limit underrun (global cut) Move the jib up to a valid radius or angle
E0147 Jib angle limit exceeded (global cut) Move the jib down to a valid radius or angle
E014A Slew angle left to large (global cut) Rotate to the permitted Working Range
E014B Slew angle right to large (global cut) Rotate to the permitted Working Range
E014C Min length limit underrun (global cut) Telescope into the permitted Working Range
E014D Max length limit exceeded (global cut) Telescope into the permitted Working Range
E014E Min height limit underrun (global cut)
Move the boom into the permitted Working Range (load
chart)
E014F Max height limit exceeded (global cut) Move the boom into the permitted Working Range
E0150 Min wind speed limit underrun (global cut) Operation is restricted to permitted conditions
E0151 Max wind speed limit exceeded (global cut) Operation is restricted to permitted conditions
E0411 Max wind speed limit exceeded (Warning) Operation is restricted to permitted conditions (load chart)
