1-36 ● Connection of signals
● The printing scan count maximum value is dependent on the printed character width
and conveyor maximum speed and calculated using the following equation.
Substitute the nozzle diameter suited for the model you are using for item d.
Printing scan count maximum value[kHz]
=conveyor maximum speed[m/min]×
1
60
horizontal dot count-1
character width[mm]-d[mm]
×
……(Equation 1)
nozzle diameter d
65µm 0.3
● Using Equation 2, check whether the printing scan count maximum value
determined by Equation 1 can be followed by the IJ printer printing speed.
kHz] >
Excitation frequency(f)
(Vertical dot count + character width setting + 1) x (ink drop use percentage)
printing scan count maximum value[kHz]……(Equation 2)
● The excitation frequency (f) value varies with the ink type employed.
Ink type
Excitation frequency
65μm Nozzle Machine
JP-K26 68.9kHz
JP-K27 68.9kHz
JP-R27 68.9kHz
JP-G27 68.9kHz
JP-K28 68.9kHz
JP-K33 74.0kHz
JP-K60 68.9kHz
JP-K61 68.9kHz
JP-K62 68.9kHz
JP-F63 68.9kHz
JP-T64 68.9kHz
JP-K65 68.9kHz
JP-K67 68.9kHz
JP-K68 68.9kHz
JP-K69 68.9kHz
JP-K70 68.9kHz
JP-T71 68.9kHz
JP-K72 68.9kHz
JP-T75 68.9kHz
JP-R76 68.9kHz
JP-K77 68.9kHz
JP-E78 68.9kHz
JP-F80 68.9kHz
JP-K81 68.9kHz
JP-B82 68.9kHz
JP-K83 68.9kHz
JP-K84 68.9kHz
JP-B85 68.9kHz
JP-K86 68.9kHz
JP-K87 68.9kHz
JP-K88 68.9kHz
JP-Y91 68.9kHz
JP-F92 68.9kHz
JP-Y94 68.9kHz
JP-B95 68.9kHz
JP-F97 74.0kHz
JP-K101 68.9kHz
JP-K106 68.9kHz
