User manual C4 – C6
13
Technical data
C4
C6
Transport length without jib
2583
2692
mm
Transport width
750
750
mm
Transport height
1780
1750
mm
Max. space outriggers extended at 45°
4440x4220
4440x4220
mm
Total weight incl. jib and any ballast
1950
2800
kg
Total weight jib
150
150
kg
Total weight jib tube
18
18
kg
Total weight ballast
114
600
kg
Weight of winch weight with hook
33
33
kg
Weight of winch head
13
13
kg
Maximum ground pressure per surface area
11
15
kg/cm
2
Maximum outrigger force per outrigger
2450
3300
kg
Max. load jib horizontal retracted
700
900
kg
Max. load jib horizontal extended
510
514
kg
Max. winch load
1000
1000
kg
Max. reeving
1x reeving 2000
kg
1x reeving 2000 kg
2x reeving 3000 kg
