User manual C4 – C6
36
6.2.4. Changing the transmitter battery
To change the battery in the transmitter, proceed as follows:
Switch off the transmitter and the machine.
Remove the battery from the transmitter (figure 27).
Figure: 27
Swap the battery in the transmitter with the battery in the battery
charger on the crane column (see figures 28 and 29). The battery on
the crane column will be charged again when the crane is used.
Attention! There is a half circle in the plastic on the battery and
another on the battery socket. Make sure these are aligned with each
other. Otherwise the battery will be backwards.
Figure: 28
Figure: 29
The machine can be started again.
See table below for meaning of the LEDs.
Left LED
Battery charger status, for troubleshooting only
Right LED
Battery status, for user
