HOEFLON C4 - Limits

User manual C4 – C6
60
6.7.6. Limits
Figure 79: 30 degree adjustable section raised
Figure 80: 30 degree adjustable section lowered
USE WITHOUT JIB
USE WITH JIB
Number
of
reevings
Min. boom
angle
Max. boom
angle
Min. jib
angle
Max. jib
angle
Winch head without
lifting weight
Not permitted
Not permitted
Not
permitted
Not
permitted
Winch head
0
0 degrees
70 degrees
-70 degrees
70 degrees
1 or 2
0 degrees
45 degrees
-70 degrees
45 degrees
30 degree adjustable
section with winch head
lowered (see Figure 80).
0
0 degrees
85 degrees
-40 degrees
70 degrees
1 or 2
0 degrees,
85 degrees, 80
degrees with
retracted boom
-70 degrees
60 degrees
30 degree adjustable
section with winch head
raised (see Figure 79).
0
0 degrees
60 degrees
-70 degrees
60 degrees
1 or 2
0 degrees
35 degrees
-70 degrees
35 degrees
