2.3. Technical data
2.3.1. Technical specifications
The technical data for the compact cranes are shown below.
General data
Machine brand
Hoeflon
Serial number
03 12 1089 C6 (1089=service number)
Jib weight
150
kg
Maximum angle of inclination
15
°
Clearance angle
20
°
Max. lean angle with outriggers extended
5
°
Ground clearance
131
mm
Petrol engine
Honda GX630 5.2 kW
Diesel engine
Yanmar 3 cylinder 7.3 kW
Electric motor
230 V 50 Hz 3.0 kW
Fuel tank volume Honda
6.1
L
Engine oil volume Honda
1.1
L
Fuel tank volume Yanmar
10
L
Engine oil volume Yanmar
2.7
L
Battery
12 V, 44 Ah
Ambient temperature
-10 to 40
°C
Slewing angle
360
°
Max. working load and lifting point of crane
See load table provided in the annexes
Maximum wind speed
10.8 (6 Beaufort)
m/s
Centre of gravity
Under the lifting hook on the top of the
boom and 950 mm from underside of
crawler track.
