HOEFLON C4 - Emergency Control

User manual C4 – C6
87
7.10. Emergency control
The emergency control may only be used when the
crane no longer functions and must be operated in an
emergency situation. All the safety measures are
bypassed and the user bears full responsibility!
Figure: 105
 Remove the round head bolts from the rear cover, and remove
the cover from the crane (see figure 106).
Figure: 106
 Unscrew the connector from the pump solenoid on the left
side (see figure 107).
Figure: 107
 Connect one plug from the emergency control set in its place
(see figures 107 and 108).
Figure: 108
