User manual C4 – C6
35
6.2.3. Calibrate levers
If the levers do not respond over the entire range of movement, they must be calibrated. This is
done as follows:
Switch on the remote control and activate the remote
control menu by pressing the ✓ button (see figure 22).
Press the button to move the arrow in the display until it
points to 'Lever calibration' (see figure 22).
Figure: 22
Press the ✓ button and you will be taken to the Calibrate
levers screen. You see a bar for each lever.
When you operate a lever the bar turns green. In the
maximum position the bar should be 100% green.
If not, the levers must be calibrated (see figure 23).
Figure: 23
Press the ✓ button and you will be taken to the next
screen. It says Put levers in center. Leave all the levers in
their middle position; do not operate them (see figure 24).
Figure: 24
Press the ✓ button and you will be taken to the next
screen. It says Move levers back en forth. Slowly operate
the levers one at a time, from the maximum backwards
position to the maximum forwards position (see figure 25).
Figure: 25
Press the ✓ button and you will be taken to the next
screen. It says Save calibration. If you now operate a lever,
the bar will turn green again in the direction you have
chosen. At the maximum forwards or backwards position,
the green bar will fill to 100%. If everything is working
properly, press the ✓ button and the settings will be saved
(see figure 26).
Figure: 26
Pressing twice will now take you back to the home screen.
