Pictogram
Meaning
Location
L to R: Do not use in the
vicinity of high voltage
cables; Suspended load; It is
prohibited to be under the
load.
On the crane
It is prohibited for
unauthorised persons to be
within the working range or
DANGER ZONE of the
machine.
On the cover of the
electrical cabinet
Check that all safety devices
are installed correctly before
starting up the machine.
On the cover of the
electrical cabinet
Always consult the user
manual before taking any
action.
On the cover of the
electrical cabinet
Attention: Raising and
lowering outriggers.
On the outriggers
Attention: When the green
lamp is on, the radio remote
control for the crane is
active.
On crane column next to
warning light
Risk of cutting or severing
On the crane at pivot points
and on the outrigger legs at
the cylinders
Electrical danger
On electrical cabinet
