User manual C4 – C6
29
Check the fuel level and top up if necessary:
Honda engine unleaded petrol (see figure 13).
Yanmar engine EN 590 diesel fuel (see figure 14).
See section 7.5 for the diesel fuel specifications.
Figure: 13
Figure: 14
Check the coolant level in the Yanmar engine
*
. When the engine is
warm the level should be at the full line and, when cold at the low
line (see figure 15).
Top up with coolant if necessary (see section 7.5 for the coolant
specifications).
Do not under any circumstances remove the cap while the engine is
warm!
If there is still coolant in the expansion tank, just fill it to the proper
level (figure 15). Otherwise also fill up the radiator (figure 16).
Remove the air filter cover, where present, and inspect the air filter
elements. Clean or replace contaminated air filter elements. Always
replace damaged air filter elements.
Visually inspect the tension and condition of the crawler tracks. If
defects are found, contact the dealer.
Raise the machine on the outriggers. When the tracks are lifted off
the ground they should not sag more than 2 cm along the bottom. If
they sag more, they must be tensioned.
The tracks are tensioned by fitting the grease gun to the grease nipple
in the centre of the track and pumping until the grease gun provides
greater resistance (figure 17). The tracks must be tight.
*
The Honda engine is air cooled.
