User manual C4 – C6
89
Unscrew the coil from the valve (see figure 110) and swap the plug
with a plug from the emergency control (see figure 105). Once this
plug is attached, the coil with plug can be reattached.
Figure: 110
Figure: 111
Screw the control handle (see figure 105) in the valve that must be
operated. (see figure 111).
Figure: 112
Remove the protective cap from the start assistance terminals (see
figure 113).
Figure: 113
Place the red clamp on the start assistance terminal with the red
protective cap, and place the black clamp on the start assistance
terminal with the black protective cap (see figure 114).
Figure: 114
