11. Maintenance Procedures
106
Without functioning parking brake, the tractor may roll away if not secured with wedges.
Disregarding this information could result in serious or fatal injuries, and damage to the
tractor.
1. Secure the tractor with wedges.
2. Pull the protective sleeve off towards the front of the tractor.
3. Unscrew the locknut a 17-mm socket or wrench until the electrical brake cylinder (?) is free of
tension.
The parking brake is now released and the tractor can be towed.
Replacing a fuse
This procedure provides instructions on how to replace fuses.
To replace a fuse:
Warning: Risk of electric shock
Cut off battery power supply before working on electrical system. Failure to comply could
result in serious or fatal injuries, and damage to the tractor.
1. Ensure that the battery disconnect switch is in position off.
2. Locate the electric panel on the right side of the cab under the console.
3. Fold flap over to open the electric panel (?).
4. Locate the damaged fuse according to the table below.
Fuse # Capacity Corresponding parts, functions
F01 15 A
l instrument panel
l remote thermometer
l hydraulics
F02 15 A reserve
F03 15 A beacon light
F04 15 A right parking light 58R
F05 15 A
l lighting on instrument panel
l hydraulic remote thermometer
l lighting of flashing warning switch
F06 15 A
l left parking light 58L
l rear number plate light
Table 11-1. Fuses
