9. Getting ready to work with attachments
61
5. Calculate the actual rear axle load (T
H tat
) according to the following formula:
T
H tat
= G
tat
- T
V tat
6. Enter the values calculated in steps 1-5 into the Front/rear weight comparison table.
7. Enter twice the value (two tires) of the actual tire load capacity (see the tire manufacturer's
specification) into the table.
Calculated value Permissible value
Double permissible tire load
capacity
Minimum weight front G
V min
Minimum weight rear G
H min
Gross weight
Front axel load
Rear axel load
Table 9-1. [Front/rear weight comparison]
The minimum weight must be applied to the tractor as an attachment or counterweight.
The calculated values must be less than or equal to the permissible weight values.
Adjusting arrester hooks
This procedure provides instructions on how to adjust the arrester hooks.
To adjust the arrester hooks:
Danger of crushing
During installation (of what?), observe that there will not be any crushing of limbs. If you do not
observe these specifications, there is the danger of injury that lead to death, severe injury or damage to
the tractor.
1 Pinch bolt
2 Front lift arm
3 Pin
4 Bent arm
5 Quick-detach coupling
6 Reducing sleeves (Cat. 2 to Cat. 1)
