11. Maintenance Procedures
108
Fuse # Capacity Corresponding parts, functions
F31 15 A
l solenoid valve
l front/rear PTO shaft
F32 15 A Bucher hydraulic pin 23, supply switch on, off
F33 15 A Bucher electronics pin 05
F34 15 A Bucher electronics pin 34
F35 20 A
l drive control unit electronics Bosch RC6-9/20 Pos. 1 + 27
l reserve movement spotlight
F36 15 A
l horn
l air filter maintenance switch
F37 1 A
l drive control unit electronics Bosch RC6-9/20 Pos. 41 + 42
l travel direction
F38 1 A
l drive control unit electronics Bosch RC6-9/20 Pos. 10, 11, 12, 23, 34, 37, 48,
61
l diagnosis socket A
l drive program switch
l inductive sensor
l reserve movement switch
Caution: Replace a defective fuse only with the fuse of the same load capacity. Failure to
comply may damage the tractor.
5. Replace the defective fuse.
Disconnecting/connecting battery
This procedure provides instructions on how to disconnect/connect the battery.
Warning: Risk of fire
Failure to comply with the following could result in injuries and damage to the tractor.
l Do not place any metal parts on battery terminals to avoid short circuit.
l Keep fuel and flammable liquids away from battery.
l Do not smoke or light an open fire while working with battery.
Warning: Risk of chemical burns
Battery acid is highly corrosive. Follow safety guidelines to avoid injuries.
Danger from electrical equipment (?)
