9. Getting ready to work with attachments
62
7 Lift hook
8 Wedge bolt
The spring washers under the nut (8) in the same direction mounting.
Lateral (is there any other?) adjustment of the arrester hook
1. Measure the bolt distances at your attachment.
2. Loosen the wedge bolts on both sides.
3. Move the lift hooks laterally until reaching the required dimension.
4. Tighten the wedge bolt.
5. You can incorporate category-2 devices directly with the arrester hook.
6. For category-1 devices, insert the adapter sleeves at the left and right.
Adjusting length of spigots
This procedure provides instructions on how to adjust the length of the spigots.
To adjust the length of the spigots:
1. Loosen the lock nuts and pinch bolt at the inside and at the bottom of the lift arm.
2. Loosen the screw on the pin and pull it out (Remove lynch pin and pull out the bolt).
3. You can adjust the bent arm to one of 3 positions (which ones?)
4. Re-insert the pin into the bore and secure with the screw (or option 2 Secure with the lynch pin).
5. Retighten the pinch bolts and lock nuts (1).
Type Position Application
Bore 1 Front Category 1 and 2
Bore 2 Center Category 1
Bore 3 Rear Special equipment (?)
Table 9-1. Types of bores
Adjusting top link slide / adjustable block
This procedure provides instructions on how to adjust the top link slide / adjustable block.
To adjust the top link slide / adjustable block:
Danger: Failure to comply with the following could result in serious or fatal
injuries, and damage to the tractor.
