9. Getting ready to work with attachments
67
Joystick level
Joystick direction
Longitudinal (forward,
backward)
Transverse (left, right)
0 (without button) front lift Y0
forward: lower
back: lift
floating position on keypad
right front plug-type coupling
X0
floating position X0 on keypad 2
1 (button 1 pressed) tipping system / rear lift
(switchable via 3-way valve)Y1
forward: lower
back: lift
floating position on keypad
right front plug-type coupling
X1
floating position X1 on keypad
2 (button 2 pressed) front left plug-type coupling Y2
no floating position provided
rear left plug-type coupling X2
no floating position provided
3 (button 3 pressed) inclination adjustment of front lift
Y3 (contained in front lift)
forward: tilt to right
backward: tilt to left
side adjustment of front lift X3
alternatively: plug-type coupling
left: swivelling to left
right: swivelling to right
Table 9-1. Proportional joystick operation, for sensitive operation
The operating conditions for the series joystick also apply for the multifunctional joystick (optional
equipment). The key numbers are identical, as for the S 1090.
1 Tipper, plug-in coupling blue
2 Plug-in coupling white, yellow
3 Quantity distributor 2, 12 Volt 1)
4 Quantity distributor 2, 12 Volt 1)
5 Device relief On, Off
6 Quick lift-out lifting
7 Float position Lift
8 Float position Incline
