DESCRIPTIONS
7
<Main Unit>
<Rear of main unit/Connection>
<Display>
Ground Terminal
To Video Signal
Cable Display
To Optional
Display
To GPS/DGPS
Antenna
Remote (4P)
Remote for OP display (4P)
DC Power Supply
(2P)
Brightness Key
(Bright)
(page 15 )
Brightness Key
(Dark)
(page 15 )
External Output (6P)
Transducer
※5P is used for 50kHz-200kHz
※(only HE-6801, HE-6901)
Display Power Supply
(5P)
OP Display (5P)
Water Temp. Sensor (8P)
1. MAIN UNIT/DISPLAY
