TO MEMORIZE (SHOW) WAYPOINT MARK
To memorize (show) waypoint mark
[Waypoint mark]
Waypoint mark is mark that indicates “destination” or “turning point”.
Shape : 8 type（）
Indicated Color: Red, Yellow, Green, Magenta, White, Cyan, Blue, Wake color
Numbers of point: up to 1,000 points
When waypoint is memorized (shown), waypoint mark and waypoint number (0999) is
shown. Number is renewed each time when waypoint is memorized newly.
However, in case there are waypoints which were erased before, number will be used
from it.
Waypoint mark will be shown when map range enlarges more than 50NM.
In case it’s range reduces less than 80NM, all waypoints will be shown by “dots”.
[Input of “Comment (Name)”]
You can add “Comment (Name)” at each waypoint mark. (page 35)
When waypoint mark is shown by dot, “Comment (Name)” is not shown.
1 2 3 4 5 6 7 8
Press [WP SAVE] key. Waypoint mark and
waypoint number are shown.
They are indicated at cursor’s position when
cursor is shown and are indicated at own boat’s
position when cursor is not shown.
1
WP SAVE key
Waypoint Mark
Waypoint Number
Change of Shape
Shape of waypoint mark is changed.
[2.WAYPOINT][6.CHANGE OF SHAPE] is
selected on the menu.
Designate desired shape of waypoint mark on [6.
CHANGE OF SHAPE].
1
2
