31
TO ERASE WAKE
To erase wake by color
All wakes which have selected by each color are
erased.
Select [1.WAKE][4.WAKE ERASE][1.ERASE
BY COLOR] on the menu.
Select and designate color among [1. ERASE BY
COLOR].
All wakes which were designated by color are
erased by pressing [SET] key.
1
2
3
SET key
[Upper limit of recording]
There is upper limit of wake which you can record. Maximum numbers of point which you
can store is 32,000 points. When wake points exceed 32,000 points, wake from the
oldest is erased.
When you sail for a long time (distance), it is recommended to set the memory interval to
long.
Please refer to [HOW TO OPERATE MENU] ( page12 ) for operation of menu.
To erase all wakes
All wakes are erased.
Select [1.WAKE] [4.ERASING WAKES]
[2.ERASE ALL] on the menu.
All wakes are erased by pressing [SET] key.
1
2
SET key
