30
TO SHOW (RECORD) WAKE
Show (Record) of wake
By pressing [WAKE ON/OFF] key, wake is
recorded. Previous recorded wake is also indicated
again. which indicates “During recording
wake” is shown on the lower left of screen.
By pressing [WAKE ON/OFF] key when wake is
recorded, record is interrupted. on lower
left of screen disappears.
You can delete record by selecting [ERASING
WAKE] on the menu.(page 31)
You can change wake color by pressing [WAKE
COLOR] key.
Wake color changes each time when you press
[WAKE COLOR] key.
(Selectable from 7 colors, Red, Yellow, Green,
Magenta, White, Cyan, Blue)
1
2
3
WAKE COLOR key
WAKE ON/OFF key
Wake Event Mark
Waypoint Mark
[Wake]
Track which own boat moved is called “Wake”. When wake is shown, wake is
continued to record. When wake is not shown, it’s recording is interrupted.
[Memory interval of wake]
Wake is continuous connected lines between each memorized own boat’s position
at certain interval. The memory interval is called “Memory interval of wake”. There
are advantages and disadvantages respectively in long interval and short interval.
Interval
Long
Short
Advantage
Long-term wake can be stored.
Wake is shown in detail.
Disadvantage
Wake is shown roughly.
Wake can be stored for a short time.
Normal wake itself can be shown
minutely. But in case picture is
displayed again, wake is shown on
the left figure as it is displayed
according to set memory interval.
To Next Page
