Chapter 3 – Configure the Printer
36 6824 Mobile Full Page Printer User Manual
Print the Configuration Page
Follow these steps to print a page showing the current printer configuration
settings and other useful information including error logs.
1 If the printer is on, turn it off.
2 Press POWER/SLEEP, and then immediately press and hold ALT. The
printer automatically restarts.
3 Release ALT. The printer prints the configuration page.
4 Press READY/CLEAR. The printer restarts.
About the Configuration Page
The printer configuration page includes these items:
• Printer serial number
• Engine serial number
• Printer configuration number
• Firmware (F/W) version
• Bootloader version
• Font version
• Total pages (printed)
• Printhead pin check pattern
Communication Settings
Serial Setting Options Default
Baud Rate 4800
9600
19200
38400
19200
Data Bit 8 BIT
7 BIT
8 BIT
Stop Bit 1 BIT
2 BIT
1 BIT
Parity NONE
EVEN
ODD
NONE
Buffer Control RTS/CTS
XON/XOFF
XON/XOFF
Note: Before you print, make sure that paper and ribbon are loaded.
