Chapter 3 – Configure the Printer
6824 Mobile Full Page Printer User Manual 41
Recommended Printhead Gap Settings
This section lists the recommended printhead gap settings for supported media
types.
Each table lists the acceptable paper thickness for each single sheet or each
sheet of multilayer paper. Total thickness must not exceed .35 mm (0.014 inch).
Note: The weight of paper may vary depending on the paper manufacturer.
One-Part Carbonless Media
Parts Spec (g/m2)
Layer Thickness
(Min–Max, in mm)
Total Thickness
(Min–Max, in mm)
Gap Setting
Single 47 to 81 .060 to .104 .060 to .104 1.0
Two-Part Carbonless or Carbon-Backed Media
Parts Spec (g/m2)
Layer Thickness
(Min–Max, in mm)
Total Thickness
(Min–Max, in mm)
Gap Setting
Top 40 to 64 .051 to .082 .103 to .186 1.1 or 1.2
Bottom 40 to 81 .051 to .082
Three-Part Carbonless or Carbon-Backed Media
Parts Spec (g/m2)
Layer Thickness
(Min–Max, in mm)
Total Thickness
(Min–Max, in mm)
Gap Setting
Top 40 to 64 .051 to .082 .154 to .269 1.2 or 2.0
Middle 40 to 64 .051 to .082
Bottom 40 to 81 .051 to .104
Four-Part Carbonless or Carbon-Backed Media
Parts Spec (g/m2)
Layer Thickness
(Min–Max, in mm)
Total Thickness
(Min–Max, in mm)
Gap Setting
Top 40 to 64 .051 to .082 .206 to .351 2.2 or 3.0
Middle 40 to 64 .051 to .082
Middle 40 to 64 .051 to .082
Bottom 40 to 81 .051 to .104
