Appendix A – Specifications and Command Lists
50 6824 Mobile Full Page Printer User Manual
Printer Specifications
Physical Specifications
Specification Description
Dimensions: Fixed mount printer with 200-sheet paper tray:
508 mm x 368 mm x 156 mm
(20 in x 14.48 in x 6.14 in)
Portable printer with 50-sheet paper tray, not including handle:
402 mm x 378 mm x 156 mm
(15.83 in x 14.88 in x 6.14 in)
Portable printer with 200-sheet paper tray, not including handle:
402 mm x 378 mm x 213 mm
(15.83 in x 14.88 in x 8.39 in)
Weight Fixed mount printer with 200-sheet paper tray: 8.86 kg (19.54 lbs)
Portable printer with 200-sheet paper tray: 8.64 kg (19.05 lbs)
Portable printer with 50-sheet paper tray: 7.97 kg (17.57 lbs)
Operating temperature: DC: –20 °C to 60 °C (–4 °F to 140 °F)
AC: –20 °C to 50 °C (–4 °F to 122 °F)
Battery Operating
Temperature
0 °C to 45°C (32 °F to 113 °F)
Storage temperature: AC/DC: –30 °C to 70 °C (–22 °F to 158 °F)
With battery: –20 °C to 60 °C (–4 °F to 140 °F)
Operating humidity: 10 to 85% non-condensing
Storage humidity: 5 to 95% non-condensing
Operating altitude: DC: Up to 5000 m
AC: Up to 2000 m
Storage altitude: Up to 15,000 m
Electrical Specifications
Specification Description
Operating voltage: Vehicle: Nominal 12 VDC and 24 VDC systems
Li Ion Battery: 14.4 V (Nominal)
AC Adapter: 100-240 V, 50/60 Hz
Current: Idle, sleep mode not charging batteries: 75 mA
Printing: 4 A (typical)
Charging internal battery: 1.2 A
Charging computer battery: Up to 0.9 A
Battery shelf life: 1 year at -20 °C to 20 °C
(-4 °F to 68 °F)
Battery: 14.4 V, 4S2P Li-ion, 5200 mAh
Battery charge time: 5 hours (0 to 40 °C charge environment) when connected to external 24 V power source
