Chapter 3 – Configure the Printer
6824 Mobile Full Page Printer User Manual 37
• Macro configuration settings:
• Typeface
• Horizontal pitch
• Vertical pitch
• Form length in inches
• Left margin
• Top of form
• Top margin
• Lines per page
• CR code
• LF code
• Code page (default is 437)
• International character set
• Zero option (default is no slash)
• Installed settings:
• Tear
• Baud rate
• Parity
• Data bit
• Stop bit
• Buffer CTL
• Sleep timeout (IDLE TO SLEEP)
• Head jam history
• Error log
About Error Log Information
The printer configuration page includes error log information. The error log
records the latest 50 errors. For each type of error, the maximum count is 65535.
When the error count reaches this value, the value does not increase and does
not reset.
Error Log Definitions
Error Type Description
Serial Serial interface communication error
Head-T Head temperature error
Insi-T Inside temperature error
HD-Jam Head jam error
System System error
