Honeywell E3 Series User Manual

12 E3 Series and S3 Series Building Blocks Reference Guide — P/N 9021-60724:A4 02/20/2019
Basic E3 Series Remote Configurations E3 Series Remote Annunciator, RAN-7100 Cabinet Ordering Information
1.6 E3 Series Remote Annunciator, RAN-7100 Cabinet
Ordering Information
The RAN-7100 model is a double module, remote annunciator cabinet that is used for display and
control. Figure 1.6.1 illustrates the remote serial annunciator, LCD display for the Gamewell RAN
retrofit. This model is installed in the GWRAN2-BB backbox.
Figure 1.6.1 E3 Series Remote Annunciator, RAN-7100 Display Panel
Figure 1.6.2 shows the RAN-7100 cabinet installation configuration.
Figure 1.6.2 E3 Remote Annunciator RAN-7100 Cabinet Configuration
10
5 ¼ ”
R
A
N
-
7
1
0
0
2
½
”
Qty Part Number Model Number Description
List
Price
Note: X represents the required components.
Cabinets Dimensions:
1 RAN-7100 10”W x 5 1/4”H x 2 1/2’D Remote Alpha-numeric display
1 GWRAN2-BB Backbox
Module
Optional Components
Table 1.6.1 E3 Remote Annunciator RAN-7100 Cabinet Ordering Information
