18 E3 Series and S3 Series Building Blocks Reference Guide — P/N 9021-60724:A4 02/20/2019
E3/S3 Series FACP Panel Configurations E3 Series Fire/Audio “C” Size Cabinet Order Information
2.4 E3 Series Fire/Audio “C” Size Cabinet Order Information
The E3 Series “C” Size Cabinet is used to house the components and amplifiers that support the E3
Series Fire and Voice Evacuation Systems. Figure 2.4.1 illustrates the E3 Series Fire/Audio “C”
Size cabinet configuration. Table 2.4.1 lists the E3 Series Fire/Audio, “C” Size cabinet ordering
information.
Figure 2.4.1 E3 Series Fire/Audio “C” Size Cabinet Configuration
-
N
G
A
C
A
B
I
N
E
T
C
T
E
L
E
P
H
O
N
E
B
O
X
I
N
I
-
V
G
S
E
R
I
E
S
C
A
B
I
N
E
T
C
A
M
-
5
0
E
X
T
E
N
D
E
R
P
L
A
T
E
A
M
-
5
0
S
E
R
I
E
S
I
L
I
-
M
B
-
E
3
I
L
I
9
5
-
M
B
-
E
3
P
M
-
9
/
P
M
-
9
G
D
A
C
T
-
E
3
R
P
T
-
E
3
Qty Part Number Model Number Description
List
Price
Note: X represents required components.
Cabinet Dimensions:
X E3BB-BC/INCC 30”H x 19 3/8”W x 4 1/2”D Enclosure, Command Center Black, “C” Size
X E3-INCC-C PLATE Mounting Plate Command Center Mounting Plate, “C” Size
X E3ID2-C 2 Slots Door Inner Door, Command Center, 2 Slots “C” Size
X LCD-E3 Display LCD Keypad Display
X 1100-0452 MIC INCC-MIC, Paging Microphone
1100-0455 ASM-16 Programmable Switch Module
1100-0451 INCC-TEL Command Center Firefighter Telephone Module
X ILI-MB-E3 System Sensor Intelligent Loop Interface, Mother Board
ILI95-MB-E3 Apollo Sensor Intelligent Loop Interface, Mother Board
X PM-9 Power Supply 9 Ampere Power Supply
INI-VGX INI-VGX Transponder Voice Gateway (3rd Generation)
1100-1323 INI-VGX-FO Transponder Voice Gateway Fiber-Optic (1st/2nd
Generation)
X 1100-1324 INI-VGX-UTP Transponder Voice Gateway Twisted-Pair Wire
X AM-50-Plate AM50-Extender Plate Amplifier Extender Plate (Supports One AM-50)
Optional Components
1100-0456 AM-50-25 AM-50 Watt Amplifier (max-1)
AM-50-70 70V Amp 70V 50 Watt amplifier (max-1)
90521 Line Filter AC Line Filter Required with 70V Amplifier
E3-TRIMKIT-C Trim Ring Kit
DACT-E3 DACT Digital Alarm Communication Transmitter
RPT-E3-UTP Networking Card Network Repeater, Unshielded Twisted-Pair Wire
FSL-E3 Fiber Networking Fiber Network Module, Single-Mode Fiber, 1 Channel
FML-E3 Fiber Networking Fiber Network Module, Multi-Mode Fiber, 1 Channel
E3-BP Blank Plate Inner Door Panel, Double Size
1100-0450 Blank Plate Inner Door Panel, Single Size
Table 2.4.1 E3 Series Fire/Audio “C” Size Cabinet Ordering Information
