E3 Series and S3 Series Building Blocks Reference Guide — P/N 9021-60724:A4 02/20/2019 35
IF600-Retrofit Backbox Ordering Information Retrofit Kit Cabinets
7.1 IF600-Retrofit Backbox Ordering Information
The IF600-Retrofit backbox is used to house the components that support the E3 Series Fire Evac-
uation System. Figure 7.1.1 illustrates the IF600-Retrofit backbox configuration. Table 7.1.1 lists
the IF600-Retrofit backbox ordering information.
Figure 7.1.1 IF600 Retrofit Backbox Configuration
AC
POW
ER
ON
POW
ER
FAUL
T
GRO
UND
FAUL
T
ALAR
M
SYST
EM
TRO
UBLE
SUPERVI
SORY
SYST
EM
SILE N
CED
ALARM
ACKNOWL
EDGE
TROUBLE
ACKNOWL
EDGE
SIGNAL
SILENCE
SYSTEM
RESET/
LAMP TEST
ME
NU
BACKSP
ACE/
EDIT
OK/
ENTER
L
C
D
-
E
3
D
A
C
T
-
E
3
R
P
T
-
E
3
I
L
I
-
M
B
-
E
3
/
I
L
I
9
5
-
M
B
-
E
3
P
M
-
9
/
P
M
-
9
G
I
F
6
0
0
-
R
E
T
R
O
F
I
T
B
A
C
K
B
O
X
Qty Part Number Model Number Description
List
Price
Note: X represents required components.
Cabinet Dimensions:
X IF600-RETROFIT 20 1/8”H x 14 1/8”W x 4 1/2”D E3BB-RBSLIM Door, Red, Back Plate
Modules
ILI-MB-E3 System Sensor Intelligent Loop Interface, Mother Board (max-1)
ILI-S-E3 System Sensor Intelligent Loop Interface, Supplemental (max-1)
X ILI95-MB-E3 Apollo Sensor Intelligent Loop Interface, Mother Board (max-1)
X ILI95-S-E3 Apollo Sensor Intelligent Loop Interface, Supplemental (max-1)
X PM-9 Power Supply 9 Ampere Power Supply
X LCD-E3 Display LCD Keypad Display
2 Batteries
Optional Components
DACT-E3 DACT Digital Alarm Communication Transmitter
RPT-E3-UTP Repeater Network Repeater, Unshielded Twisted-Pair
RPT-E3-FO Repeater Network Repeater, Fiber-Optic
75687 Cable 75687-A Special Order Cable
Table 7.1.1 IF600 Retrofit Backbox Ordering Information
