22 E3 Series and S3 Series Building Blocks Reference Guide — P/N 9021-60724:A4 02/20/2019
Basic E3 Series In-Building Mass Notification Cabinet Configurations E3 Series ACU “C” Size Cabinet used for Combination
3.1 E3 Series ACU “C” Size Cabinet used for Combination
Fire/MNS System (NGA Display) Ordering Information
The E3 Series ACU “C” Size Cabinet is used to house the components that support the E3 Series
Combined Fire/Mass Notification System. Figure 3.1.1 illustrates the E3 Series ACU “C” Size cab-
inet configuration. Table 3.1.1 lists the E3 Series ACU “C” Size cabinet ordering information.
Figure 3.1.1 E3 Series ACU “C” Size Configuration
D
A
C
T
-
E
3
R
P
T
-
E
3
P
M
-
9
/
P
M
-
9
G
I
N
I
-
V
G
S
E
R
I
E
S
I
L
I
-
M
B
-
E
3
/
I
L
I
9
5
-
M
B
-
E
3
C
A
B
I
N
E
T
C
,
A
M
-
5
0
E
X
T
E
N
D
E
R
P
L
A
T
E
A
M
-
5
0
S
E
R
I
E
S
NGA
T
E
L
E
P
H
O
N
E
B
O
X
Qty Part Number Model Number Description List Price
Note: X represents the required components.
Cabinet Dimensions:
X E3BB-BC/INCC 30”H x 19 3/8”W x 4 1/2”D Enclosure, Command Center Black, “C” Size
X E3-INCC-C PLATE Mounting Plate Command Center Mounting Plate, “C” Size
X E3ID3-C 3 Slots Door Inner Door, Command Center, 3 Slots “C” Size
Modules
NGA NGA NGA, Network Graphic Annunciator (2nd Generation)
X 1100-0505 NGA NGA, Network Graphic Annunciator (1st Generation)
X 1100-0452 MIC INCC-MIC, Paging Microphone
1100-0455 ASM-16 Programmable Switch Module
1100-0451 INCC-TEL Command Center Firefighter Telephone Module
X ILI-MB-E3 System Sensor Intelligent Loop Interface, Mother Board (max-1)
ILI95-MB-E3 Apollo Sensor Intelligent Loop Interface, Mother Board (max-2)
X PM-9 Power Supply 9 Ampere Power Supply
INI-VGC INI-VGC Command Center Voice Gateway (3rd Generation)
1100-1321 INI-VGC-FO Command Center Voice Gateway Fiber-Optic
1100-1322 INI-VGC-UTP Command Center Voice Gateway Twisted-Pair
INI-VGX INI-VGX Transponder Voice Gateway (3rd Generation)
1100-1323 INI-VGX-FO Transponder Voice Gateway Fiber-Optic
1100-1324 INI-VGX-UTP Transponder Voice Gateway Twisted-Pair Wire
INI-VGE INI-VGE Classic Voice Gateway (3rd Generation)
1100-1325 INI-VGE-FO Classic Voice Gateway Fiber-Optic
1100-1326 INI-VGE-UTP Classic Voice Gateway Twisted-Pair Wire
Optional Components
AM-50-Plate AM50-Extender Plate Amplifier Extender Plate (Supports One AM-50)
1100-0456 AM-50-25 AM-50 Watt Amplifier (max-1)
AM-50-70 70V Amp 70V 50 Watt amplifier (max-1)
90521 Line Filter AC Line Filter Required with 70V Amplifier
90492 Thumb Lock Thumb Quarter Turn Latch
E3-TRIMKIT-C Trim Ring Kit
DACT-E3 DACT Digital Alarm Communication Transmitter
RPT-E3-UTP Networking Card Network Repeater, Unshielded Twisted-Pair
FSL-E3 Fiber Networking Fiber Network Module, Single-Mode Fiber, 1 Channel
FML-E3 Fiber Networking Fiber Network Module, Multi-Mode Fiber, 1 Channel
Table 3.1.1 E3 Series ACU “C” Size Cabinet for Combination Fire/MNS System Ordering Information
