System (2)
4 - 17 Model 1010 Application Pack CB Part No.: 4418024 - Rev. 1
Programming Manual
Output type: GP OUTPUT # n allows selection of the type of output.
NOTE: Refer to the Application Pack for the default settings of GP outputs.
Select one of the following options:
None
Alarm
Stream Control
Control Valve
Additive Output
Internal Additive
RIT
If Output type is selected as Alarm, one of the following functions can be
assigned to the selected output:
Deadman Indicator
Output Relay closes when the first (warning) Deadman timeout
period expires.
Deadman Bell
Output Relay closes when the second (pause) Deadman timeout
period expires.
Deadman Callout
Output Relay closes when the third (terminate) Deadman timeout
period expires.
13 B7 BA10/BA11
14 B8 BA12/BA11
15 B9 BA13/BA14
16 B10 BA15/BA14
17 B11 BA16/BA17
18 B12 BA18/BA17
19 B13 BB1/BB2
20 B14 BB3/BB2
21 B15 BB4/BB5
22 B16 BB6/BB5
23 B17 BB7/BB8
24 B18 BB9/BB8
25 B19 BB10/BB11
26 B20 BB12/BB11
27 B21 BB13/BB14
28 B22 BB15/BB14
29 B23 BB16/BB17
30 B24 BB18/BB17
GP Output Relay Terminal
