Honeywell FUSION User Manual

SEARCH OPTIONS
6–17
6.15 STATUS SEARCH, CONTINUED
1 2 3
1 Camera
Displays the cameras in linear format.
Scroll down using the scroll bar on the right.
2 Hours
The hours 0-23 (24 hours) are listed.
3 Recording Block
Displays in blue where video is recorded.
Areas of no recording are displayed in white.
6.15.1 PERFORMING A STATUS SEARCH
1. Select the Status Search button to open the Status Search window.
2. Use the mouse to click on an area of the blue recording block.
Only one camera can be displayed at a time.
6.16 AUDIO
Audio is played back at 48,000Hz.
To play audio with the video:
1. Select a single camera by turning off all cameras but one using the
Camera Select buttons. The audio buttons will be displayed.
2. Select a single audio channel to play. When an audio channel is selected, the
Time Synch button will automatically be selected.
3. Press the Play button.

Honeywell FUSION Specifications

General

Recording Resolution	Up to 1080p
Operating System	Embedded Linux
Compression	H.264
Video Inputs	4, 8, 16
Video Output	HDMI, VGA
Network Interface	10/100 Mbps
Channels	4, 8, 16
Remote Viewing	Yes
Alarm Inputs	4
Operating Temperature	0°C to 40°C (32°F to 104°F)
Audio Inputs/Outputs	1/1 (RCA)
