DVR BASICS
4–7
4.7 TV OUTPUT CONTROLS (OPTIONAL)
The TV OUT options allows manual control the 4 analog outputs on the back of the
DVR. Within setup the outputs can be programmed to sequence through any number
of cameras, however, by using the TV OUT options that defined sequence can be
temporarily stopped and a camera can be manually selected to output. The sequence
can be easily reactivated by simply enabling the sequence again.
2
1
3
1 Close
Closes the TV Output Controls
2 Camera Select
Selects a camera to output on the selected channel.
3 AUTO On/Off
Re-enables the Auto-Sequence for the selected
channel (as defined inside setup).
TV Out 4
TV Out 3
TV Out 2
TV Out 1
