FUSION DVR Digital Recording and Transmission System
5–12
5.5 FRAME SETUP, CONTINUED
1 Set Default
Selecting this option resets all camera frames and
resolutions to the default settings.
2 Camera Number
The cameras are given different numbers to
distinguish them when viewing the frame status.
Adjust the recorded frames per second by sliding the
bar to the left and right.
3 Number of Frames
Displays the number of frames that are selected for
each camera.
4 Frame Select
Adjusts the frames for each camera.
5 Resolution
Displays the available resolution options.
See additional information below.
6 Quality
Affects the quality of the video. Increasing the quality
of the camera can considerably reduce the amount of
pixilation within the image, but it also increases the file
size.
7 Sensitivity
Adjusts the rate at which the key frame refreshes.
Sensitivity directly affects the codec being used to
record the video. Adjusting this setting can have
drastic negative effect on the quality of the video.
It is highly recommended that this setting always be
left at the default setting unless instructed by a system
administrator.
Resolution affects the total number of frames per second that are available.
The table below breaks down the number of frames available on a 240IPS DVR.
Frames Available on Fusion DVRs
240 IPS 480 IPS
Resolution Available Frames
360 x 240 240 480
720 x 240 120 240
720 x 480 60 120
