Honeywell H4W2PER2 Series - Nas; Figure 8-5 SFTP; Figure 8-6 NAS; Table 8-2 SFTP Configurations

Performance Series IP Camera Software Configuration Guide
70
Figure 8-5 SFTP
Table 8-2 SFTP Configurations
Parameter Function
Enable Check to enable the SFTP storage function.
Server Address Enter the IP address of the SFTP server.
Port
The default setting is 21. You can modify this setting as
necessary.
Username Enter the server user name.
Password Enter the server password.
Remote Directory
Create a name for the directory where recorded video and
snapshots will be stored.
Emergency
(Local)
Select Emergency (Local), and when the SFTP server does not
work, all the files are saved to the internal SD card.
NAS
On the NAS tab, you can enable network attached storage and configure storage settings.
Figure 8-6 NAS
Table 8-3 NAS Configurations
Parameter Function
Enable Select the checkbox to enable this function.
Server Address Set the IP address of the server.
