Configuration | 39
800-22740 - A - 02-2017
Configuring Video Overlay
Figure 3-4 Video Overlay Configurations
Configuring the Save Path
Configure the save path for snapped images (click in the preview interface) or recorded
video (click in the preview interface).
Table 3-4 Video Overlay Configurations
Setting Description
Cover-Area 1. Select Preview or Record.
2. Click Set, then draw a privacy mask on the specified video
in preview or on monitor video.
The DVR system supports a maximum of four privacy zones.
Channel Display Enable this function so that the system overlays channel
information in the video window.
Use the mouse to drag the channel display into position.
You can see the channel on the live WEB video or the
playback video.
Time Display Enable this function so that the system overlays time
information in the video window.
Use the mouse to drag the time display into position.
You can see the time on the live WEB video or the playback
video.
To Next Page
