Configuration | 47
800-22740 - A - 02-2017
Figure 3-13 CDMA/GPRS Configuration Interface
Configuring the Mobile Settings
Click the Mobile Setup tab in the Network Configuration interface to open the Mobile Setup
configuration interface.
Table 3-7 3G/4G Configurations
Configuration Description
WLAN Type Select a 3G network type to distinguish this 3G module from
different ISPs. Choose from WCDMA, CDMA1x, for example.
APN & Dial No. APN and the Dial No. are important PPPoE parameters. The
APN (Access Point Name) and the Dial No. are automatically
received by the DVR after connecting to a 3G module.
AUTH Authorization. Choose from PAP, CHAP, or NO_AUTH.
User Name Enter a user name.
Password Enter a password.
Pulse Interval Configure a time for ending the 3G connection after you close
the extra stream monitor. For example, if you select 60 here,
the DVR ends the 3G connection 60 seconds after you close
the extra stream monitor.
Note If the Pulse Interval is 0, then the system does not end the 3G connection after you
close the extra stream monitor.
Note The Pulse Interval here is for the extra stream only. This field is inactive if you are
using a main stream monitor.
IP Address Enter the DVR’s IP address that was searched for and
connected via the Wifi network.
Wireless Signal Click to search for and find wireless signals.
