30 MPA2C3 Installation Guide
4-door System Wiring Overview
The standard metal enclosure is equipped with the panel MPA2C3 or the 4-door
licensed panel MPA2C3-4.
The access control unit with the 4-door license controls up to 4 doors. The figure
below illustrates how to connect cables between the panel and input/output
devices of 4 doors (standard metal enclosure). This figure takes PoE+ as an exam-
ple. For the standard metal enclosure, PSU with a backup battery is also supported.
LAN/WAN
Ethernet/Internet
CAT6E STP Cable (RJ45)
Strike
Exit Device
REX
Door
Contact
Reader
Strike
Exit Device
REX
Door
Contact
Reader
Strike
Exit Device
REX
Door
Contact
Reader
Strike
Exit Device
REX
Door
Contact
Reader
Door 4
Door 2
Door 1
Door 3
Door Connections (RJ 45 or Push-in Connectors)
CAT6E STP/UTP Cable (RJ45)
Reader Connections (Wiegand/OSDP - RJ45)
CAT6E STP Cable (RJ45)
UP TO 4 DOORS
MPA2S5
Cable
MPA2S5
Cable
MPA2S5
Cable
MPA2S5
Cable
Door 3
Door 4
