EVS Series Manual — P/N LS10062-001SK-E:D 3/15/2022 29
Installing the EVS-125W EVS Device Installation
3. Secure the supplied “L-shaped” bracket to the top mounting bracket on the EVS-125WBD with the two mounting screws.
4. Align the mounting holes on the bracket with the enclosure.
5. Secure the board to the enclosure.
6. Restore AC power and reconnect the backup batteries.
B
A
T
T
E
R
Y
+
–
CIRCUIT 4 CIRCUIT 3 CI RCUIT 2 CIRCUIT 1
IN
IN IN
IN+
++
+–
––
–OUT
OUT OUT
OUT+
++
+–
––
–
AUDIO EXPANDER
B
G
W
Figure 4.25 EVS-125WBD Mounting Bracket
ON
12345
B
A
T
T
E
R
Y
+
–
CIRCUIT 4 CIRCUIT 3 CIRCUIT 2 CIRCUIT 1
IN
IN IN I N
+
+++
–
–––
OUT
OUT OUT OUT
+
+++
–
–––
AUDIOEXPANDER
Figure 4.26 EVS-125WBD In Enclosure
“L-shaped”
mounting bracket
