Honeywell Touchpoint Plus Technical Handbook

Configurable Parameter Reference Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 137 Technical Handbook
Parameter Name
Parameter Description
Applies
to
Read/
Write
Range
Default Value
Remark
Target Resolution
Resolution
mA Input
R
0.001~100
0.1
0.001, 0.002, 0.005, 0.01,
0.02, 0.05, 0.1, 0.2, 0.5, 1,
2, 5, 10, 20, 50, 100
Inhibit Time-out
Inhibit Time-out
mA Input
R/W
0~60
10
0: Disable , minute
Alarm Latch
Alarm will be continued until manual user
reset if latching is enabled.
mA Input
R/W
Disable/Enable
Enable
per channel
Calibration Interval
0, 30 to 365
mA Input
R/W
0, 30 to 365
180
0 : Disable
Target Full Range
Min full range, Max full range and user
mA Input
R/W
0~100000
Max full range
Write available when:
Detector Name- User
Detector. Max range in
catalogue file
Threshold Alarm
Hysteresis
Alarm hysteresis is to avoid the alarm from
frequent on/off when the gas reading is
close to the alarm threshold.
mA Input
R/W
0~10
2% of Full range
Alarm 1 Enable
Alarm 1 enable/disable
mA Input
R/W
Disable/Enable
Disable
Alarm 1 Threshold
Trigger
Alarm 1 trigger option (Rising or Falling)
mA Input
R/W
Rising/Falling
Rising
Alarm 1 Level
Alarm 1 threshold concentration
mA Input
R/W
2%FSD ~
100%FSD
20% of Full range
Alarm 2 Enable
Alarm 2 enable/disable
mA Input
R/W
Disable/Enable
Disable
Alarm 2 Threshold
Trigger
Alarm 2 trigger option (Rising or Falling)
mA Input
R/W
Rising/Falling
Rising
0 Rising, 1 Falling
Alarm 2 Level
Alarm 2 threshold concentration
mA Input
R/W
2%FSD ~
100%FSD
40% of Full range
Alarm 3 Enable
Alarm 3 enable/disable
mA Input
R/W
Disable/Enable
Disable
Alarm 3 Threshold
Trigger
Alarm 3 threshold concentration
mA Input
R/W
Rising/Falling
Rising
Alarm 3 Level
Alarm 3 threshold concentration
mA Input
R/W
2%FSD ~
100%FSD
60% of Full range

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
