Page #138 background imageLoading...
Page #138 background image
Configurable Parameter Reference Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 138 Technical Handbook
Parameter Name
Parameter Description
Applies
to
Read/
Write
Range
Default Value
Remark
Gas Type
Gas Type
mA Input
R/W
0~2
Gas Type
Depend on Gas Name.
Toxic(0) O2(1) Flammable(2)
Flame(3)
STEL Interval *
10, 15, 20, 25, 30
mA Input
R/W
10, 15, 20, 25,
30
15
Minute
Lower Zero Dead
Band
The gas concentration within the dead
band limit will be suppressed to default
base concentration. i.e. if the gas
concentration is between the (default base
concentration lower dead band) and
(default base concentration + upper dead
band), then the reading will be the default
base concentration.
mA Input
R/W
-20 ~ 0 % FSD
0
In case O2 :20.9%
Upper Zero Dead
Band
mA Input
R/W
0 ~ 20% FSD
0
In case O2 :20.9%
Gas Over Range
Limit
Over-range gas concentration limit. This
parameter is used to generate over-range
warning.
mA Input
R/W
100% ~
110%FSD
110 %FSD
Gas Under Range
Limit
Negative reading limit
mA Input
R/W
-24% ~ 0%FSD
-10 %FSD
Span Calibration
Conc.
Target span gas concentration
mA Input
R/W
20 ~ 100 %FSD
50% of Full range
Oxygen needs just span
calibration. No zero
calibration required.
Signal Under Range
Limit
Lower allowable limit for the input signal
from the sensor/detector.
mA Input
R/W
0
0
To diagnose the mA input
current
Signal Over Range
Limit
Upper allowable limit for the input signal
from the sensor/detector.
mA Input
R/W
20~24mA
Depend on
detector
To diagnose the mA input
current
Signal Inhibit Min.
minimum inhibit current from mA output
sensor
mA Input
R/W
0~24
1.9 mA
if min/max is set to zero, mA
input board will not detect
inhibit condition.
Signal Inhibit Max.
maximum inhibit current from mA output
sensor
mA Input
R/W
0~24
2.1 mA
Signal Fault Min.
minimum fault current from mA output
sensor
mA Input
R/W
0~24
0.0 mA
if min/max is set to zero, mA
input board will not detect
fault condition.
