Honeywell Touchpoint Plus Technical Handbook

Configurable Parameter Reference Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 142 Technical Handbook
Parameter Name
Parameter Description
Applies
to
Read/
Write
Range
Default Value
Remark
Span Calibration Gas
Span Calibration Gas name string
mV Input
R/W
Alphanumeric
Character
Range
16 chars
If custom is selected gas as
target calibration gas, the
span calibration gas name
can be edited. Otherwise it
should come from selected
sensor catalogue.
Channel Enable
Channel Enable/Disable
Relay
Output
R/W
Disable/Enable
Disable
Channel Number
Number
Relay
Output
R
1~48
-
An unique number
(Auto assigning 1~16 LED )
Channel ID will be
automatically assigned
Channel Tag
25 characters
Relay
Output
R/W
Alphanumeric
Character
Range
50 chars
Normal State
Energized/De-Energised
Relay
Output
R/W
Energized
/De-Energised
Energized
Alarm Update
Function
If enabled, only unacknowledged alarm
conditions will be
considered during C&E evaluation for this
output channel.
An alarm acknowledgement will reset a
relay output that
is configured for alarm update function.
However if the alarm update is NOT enabled
the relay
contact will only be reset if the alarm is
reset.
Relay
Output
R/W
Enable/Disable
Disable
Activate Delay Time
Delay time to activate the relay
Relay
Output
R/W
0~3000
0 sec
Relay Hold Time
Delay time to de-activate the relay
Relay
Output
R/W
0~3000
0 sec

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
