Honeywell Touchpoint Plus Technical Handbook

Configurable Parameter Reference Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 143 Technical Handbook
Parameter Name
Parameter Description
Applies
to
Read/
Write
Range
Default Value
Remark
Alarm 1 Event
Alarm 1 event
Relay
Output
R/W
Enable/Disable
Disable
Total channel # =
Anal_In(16) + Modbus(96)
Alarm 1 Vote Count
Set a minimum count of alarm 1 event to
trigger a relay
Relay
Output
R/W
0~16
0
1~selected channel #
Alarm 2 Event
Alarm 2 event
Relay
Output
R/W
Enable/Disable
Disable
Total channel # =
Anal_In(16) + Modbus(96)
Alarm 2 Vote Count
Set a minimum count of alarm 2 event to
trigger a relay
Relay
Output
R/W
0~16
0
1~selected channel #
Alarm 3 Event
Alarm 3 event
Relay
Output
R/W
Enable/Disable
Disable
Total channel # =
Anal_In(16) + Modbus(96)
Alarm 3 Vote Count
Set a minimum count of alarm 3 event to
trigger a relay
Relay
Output
R/W
0~16
0
1~selected channel #
Fault Event
Fault Event
Relay
Output
R/W
Enable/Disable
Disable
Total channel # =
Anal_In(16) + Modbus(96)
Fault Vote Count
Set a minimum count of Fault event to
trigger a relay
Relay
Output
R/W
0~16
0
1~selected channel #
Warning Event
Warning Event
Relay
Output
R/W
Enable/Disable
Disable
Total channel # =
Anal_In(16) + Modbus(96)
Warning Vote Count
Set a minimum count of Warning event to
trigger a relay
Relay
Output
R/W
0~16
0
1~selected channel #
Inhibit Event
Inhibit Event
Relay
Output
R/W
Enable/Disable
Disable
Total channel # =
Anal_In(16) + Modbus(96)
Inhibit Vote Count
Set a minimum count of Inhibit event to
trigger a relay
Relay
Output
R/W
0~16
0
1~selected channel #
Vote Count
Reduction on fault
0: reduction, 1: no reduction
Relay
Output
R/W
Check/not
check
Check
Vote Count
Reduction on inhibit
0: reduction, 1: no reduction
Relay
Output
R/W
Check/not
check
Check
Channel Enable
Channel Enable/Disable
mA
Output
R/W
TRUE/FALSE
Disable
Channel Number
Number
mA
Output
R
1~16
-
Channel ID will be
automatically assigned

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
