Honeywell Touchpoint Plus Technical Handbook

Configurable Parameter Reference Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 144 Technical Handbook
Parameter Name
Parameter Description
Applies
to
Read/
Write
Range
Default Value
Remark
Channel Tag
25 characters
mA
Output
R/W
unicode 50
chars
Output Channel
Output Function
Channel
mA
Output
R/W
Enable/Disable
Disable
Only mA and mV input
channel can be linked to this
Inhibit Output Level
1.0 1.5 2.0 2.5 3.0 3.5 User
mA
Output
R/W
0~23.5
2.0 mA
Fault Output Level
1.0 1.5 2.0 2.5 3.0 3.5 User
mA
Output
R/W
0~23.5
1.0 mA
Warning Output
Level
1.0 1.5 2.0 2.5 3.0 3.5 User
mA
Output
R/W
0~23.5
3.0 mA
Over-range Output
Level
20.5, 21.0, 21.5
mA
Output
R/W
20.5, 21.0, 21.5
20.5
Web Access
Enable/disable Web service
System
R/W
Enable/Disable
Disable
disable: Not available WEB
DHCP Enable
DHCP / manual IP setting
System
R/W
Enable/Disable
Disable
Static IP Address
Static IP Address
System
R/W
Alphanumeric
Character
Range
192.168.0.100
xxx.xxx.xxx.xxx
Static Subnet
Address
Static Subnet Address
System
R/W
Alphanumeric
Character
Range
255.255.255.0
xxx.xxx.xxx.xxx
Static Gateway
Address
Static Gateway Address
System
R/W
Alphanumeric
Character
Range
192.168.0.1
xxx.xxx.xxx.xxx
MAC Address
max 20 characters
System
R
NA
NA
xx-xx-xx-xx-xx-xx. Writing is
only possible during
production.
Operator Password
Password for Access Level Operator
System
R/W
35 chars
TPPL

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
