Honeywell Touchpoint Plus Technical Handbook

Event Codes
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 150 Technical Handbook
Event
Type
Code
Long Description
Triggered
Display in Event
History
Details
Warning
7
IP conflicts detected
UI Board
IP Conflicts
xxx.xxx.xxx.xxx
Warning
8
Remote warning informed by detector
IO board
Detector In warning
CH: xx
Warning
9
Language memory corrupted
UI Board
Language memory
fault
Warning
10
Log memory corrupted
UI Board
Log memory fault
Warning
11
Warning self-cleared (non-latching)
Main Board
Warning Cleared
CH: xx, Code: xx
Code
A warning number
(1~14)
Warning
12
Reset all warnings by a user
Main Board
Reset all warning
Warning
13
SD Card Corrupted
UI Board
SD Card fault
Warning
14
Too many unsuccessful login attempts
UI Board
10 times' login failed
Info
1
Instrument power on
UI Board
Unit powered on
Info
2
Switched into power-off mode
UI Board
RESERVED
Info
3
Instrument rebooted automatically
UI Board
RESERVED
Info
4
Instrument power changed from AC to DC
Main Board
Switched to Battery
[Enclosure]
Enclosure
0: master enclosure,
1: extension enclosure
Info
5
Instrument power changed from DC to AC
Main Board
Switched to AC
[Enclosure]
Enclosure
0: master enclosure,
1: extension enclosure
Info
6
Added IO board
UI Board
Added IO board
[B/D Type], Slot: xx-x
B/D type
0:Main, 1:UI, 2:mA
Input, 3: mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Slot
Refer to the note 1
Info
7
Removed IO board
UI Board
Remove IO board
[B/D Type], Slot:xx-x
B/D type
0:Main, 1:UI, 2:mA
Input, 3: mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Info
8
Replaced IO board
UI Board
Replaced IO board
[B/D Type], Slot: xx-x
B/D type
0:Main, 1:UI, 2:mA
Input, 3: mV input,
4:Relay, 5:mA output,
7:Modbus,
7:Extension power
Slot
Refer to Note 1
